CyberPower Medical 1100VA

Cyberpower

CyberPower Medical 1100VA

Part #: M1100XL Uninterruptible Power Supplies (UPSs)

$728.99

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

880W (6) NEMA 5-15R-HG SNMP XL 60601-1 3YR WTY

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	8 h
Battery capacity	9 Ah
Number of batteries supported	3
Typical backup time at half load	25 min
Typical backup time at full load	10 min
Hot-swap battery	Yes
Battery voltage	12 V

Design

Form factor	Mini Tower
Product colour	White
Safety	UL1778, CSA, FCC 15 A (EMI), UL60601-1
Display type	LCD

General

Manufacturer Part Number	M1100XL
Country of Origin	CN

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)

Packaging content

Cables included	Serial, USB cable
Manual	Yes

Performance

LED indicators	Power
Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Pseudo sine
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Automatic Voltage Regulation (AVR)	Yes
Power protection features	Overload
Transfer time (Line Mode to Battery Mode)	10 ms

Physical

Weight	58.1 lb

Ports & interfaces

AC outlets quantity	6 AC outlet(s)
AC outlet types	NEMA 5-15R
Power plug	NEMA 5-15P-HG
Cable length	70.9" (1.8 m)
USB 2.0 ports quantity	1
USB port	Yes
USB port type	USB Type-B
Serial interface type	RS-232
Serial interface	Yes
RS-232 ports	1
Socket circuit breaker	Yes

Power

Input operation voltage (min)	88 V
Input operation voltage (max)	150 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Maximum current	10 A
Output frequency	60 Hz
Output power	880 W
Surge energy rating	1445 J
Output power capacity	1.1 kVA
Input frequency	60 Hz

Technical details

Compliance certificates	RoHS

Weight & dimensions

Width	8.66" (220 mm)
Height	6.69" (170 mm)
Depth	17" (431 mm)
