CyberPower Medical 550VA

Cyberpower

CyberPower Medical 550VA

Part #: M550L Uninterruptible Power Supplies (UPSs)

$490.95

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

440W (4) NEMA 5-15R-HG 60601-1 Tested 3YR WTY

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	7 Ah
Number of batteries supported	2
Typical backup time at half load	25 min
Typical backup time at full load	8 min
Hot-swap battery	Yes
Battery voltage	12 V
Battery recharge time(90%)	8 h

Design

Form factor	Mini Tower
Product colour	White
Safety	UL1778, CSA, FCC 15 A (EMI), UL60601-1
Display type	LCD

General

Manufacturer Part Number	M550L
Country of Origin	CN

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)

Packaging content

Cables included	Serial, USB cable
Manual	Yes

Performance

Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Pseudo sine
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Automatic Voltage Regulation (AVR)	Yes
Power protection features	Overload
Transfer time (Line Mode to Battery Mode)	10 ms

Physical

Weight	32.8 lb

Ports & interfaces

AC outlets quantity	4 AC outlet(s)
AC outlet types	NEMA 5-15R
Power plug	NEMA 5-15P-HG
Cable length	70.9" (1.8 m)
USB 2.0 ports quantity	1
USB port	Yes
USB port type	USB Type-B
Serial interface type	RS-232
Serial interface	Yes
RS-232 ports	1
Socket circuit breaker	Yes

Power

Input operation voltage (min)	88 V
Input operation voltage (max)	150 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Maximum current	10 A
Output frequency	60 Hz
Output power	440 W
Surge energy rating	1445 J
Output power capacity	0.55 kVA
Input frequency	60 Hz
Output power factor	0.8

Technical details

Compliance certificates	RoHS

Weight & dimensions

Width	6.38" (162 mm)
Height	5.39" (137 mm)
Depth	13.7" (347 mm)
