750VA/600W Hospital/Medical UPS Systems

Cyberpower

750VA/600W Hospital/Medical UPS Systems

Part #: M750L Uninterruptible Power Supplies (UPSs)

$616.99

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

750VA/600W Hospital/Medical UPS Systems 120 VAC, NEMA 5-15P-HG, Mini-Tower

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	7 Ah
Number of batteries supported	3
Typical backup time at half load	30 min
Typical backup time at full load	12 min
Hot-swap battery	Yes
Battery voltage	12 V
Battery recharge time(90%)	8 h

Design

Form factor	Mini Tower
Product colour	White
Safety	UL1778, CSA, FCC 15 A (EMI), UL60601-1
Display type	LCD

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)

Packaging data

Manual	Yes
Cables included	Serial, USB cable

Performance

Audible alarm modes	Alarm when on battery, Fault, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Pseudo sine
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Automatic Voltage Regulation (AVR)	Yes
Power protection features	Overload
Transfer time (Line Mode to Battery Mode)	10 ms

Ports & interfaces

AC outlets quantity	6 AC outlet(s)
AC outlet types	NEMA 5-15R
Power plug	NEMA 5-15P-HG
Cable length	70.9" (1.8 m)
USB 2.0 ports quantity	1
USB port	Yes
USB port type	USB Type-B
Serial interface type	RS-232
Serial interface	Yes
RS-232 ports	1
Socket circuit breaker	Yes

Power

Input operation voltage (min)	88 V
Input operation voltage (max)	150 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Output frequency	60 Hz
Output power	600 W
Surge energy rating	1445 J
Output power capacity	0.75 kVA
Input frequency	60 Hz
Output power factor	0.8

Technical details

Compliance certificates	RoHS

Weight & dimensions

Weight	52.7 lbs (23.9 kg)
Width	8.66" (220 mm)
Height	6.69" (170 mm)
Depth	17" (431 mm)
