1000VA Online UPS with SNMP

Cyberpower

1000VA Online UPS with SNMP

Part #: OL1000RTXL2UN Uninterruptible Power Supplies (UPSs)

$1,121.99

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

Cyberpower 1000VA Online UPS with SNMP

Specifications

Battery

Battery recharge time	4 h
Battery capacity	9 Ah
Typical backup time at half load	20 min
Typical backup time at full load	7.4 min
Cold start	Yes
Hot-swap battery	Yes
Replacement battery cartridge	RB1290X3L
Battery voltage	12 V
Number of battery cells	3

Design

Form factor	Rackmount/Tower
Rack capacity	2U
Product colour	Black
Safety	UL 1778 5th Ed.CSA C22.2 NO.107.3-05FCC Part 15 Class A CSA C22.2 NO.107.3-05 FCC Part 15 Class B
Display type	LCD
Housing material	Steel

General

Manufacturer Part Number	OL1000RTXL2UN
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 45 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%

Packaging data

Manual	Yes
Cables included	Phone (RJ-11), Serial, USB cable
Rack mount kit	Yes

Performance

LED indicators	Yes
Audible alarm modes	Fault, Low battery alarm, Overload alarm
UPS topology	Double-conversion (Online)
Waveform	Sine
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Network, Telephone

Physical

Weight	53.5 lb

Ports & interfaces

AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5–15R
Power plug	NEMA 5-15P
Cable length	118.1" (3 m)
Ethernet LAN (RJ-45) ports	1
Serial ports quantity	1
USB port	Yes
Emergency Power Off (EPO) connector	Yes
Modem (RJ-11) ports	1

Power

Input operation voltage (min)	60 V
Input operation voltage (max)	150 V
Output operation voltage (min)	100 V
Output operation voltage (max)	125 V
Output frequency	50/60 Hz
Output power	900 W
Output power capacity	1 kVA
Input frequency	40/70 Hz
Output frequency regulation	0.25 Hz
Crest factor	3:1
Output voltage Total Harmonic Distortion (THD)	3%
ECO mode	Yes
Input power factor	0.99
Efficiency (ECO mode)	94%
Output power factor	0.9

Technical details

Compliance certificates	RoHS

Weight & dimensions

Width	17" (432 mm)
Height	3.46" (88 mm)
Depth	16.9" (429 mm)
Package width	21.5" (546.1 mm)
Package height	9.27" (235.5 mm)
Package depth	22.5" (571.5 mm)
Package weight	0.856 oz (24.3 g)
