Cyberpower

1.5KVA Online UPS 2U

Part #: OL1500RTXL2UN Uninterruptible Power Supplies (UPSs)

$1,775.95

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

11.5KVA ONLINE UPS 2U - SINEWAVE LCD 5-15P 100-125V RMCARD205 RT 3YR WTY

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	4 h
Battery capacity	12 VAh, 9 Ah
Number of batteries supported	3
Typical backup time at half load	11 min
Typical backup time at full load	3 min
Hot-swap battery	Yes
Replacement battery cartridge	RB1290X3L

Design

Form factor	Rackmount/Tower
Rack capacity	2U
Product colour	Black
Safety	UL1778, CSA C22.2 NO.107.3-05, FCC DOC Class B
Display type	LCD
Housing material	Steel

General

Manufacturer Part Number	OL1500RTXL2UN
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 45 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)

Packaging data

Manual	Yes
Cables included	Phone (RJ-11), Serial, USB cable
Rack mount kit	Yes
Warranty card	Yes

Performance

LED indicators	Power, Battery replacement
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm, Battery replacement
UPS topology	Double-conversion (Online)
Waveform	Sine
Noise level	50 dB
Audible alarm(s)	No
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Network, Telephone
Power protection features	Short circuit

Physical

Weight	53.95 lb

Ports & interfaces

AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5–15R
Power plug	NEMA 5-15P
Cable length	119.7" (3.04 m)
Ethernet LAN (RJ-45) ports	2
USB port	Yes
Emergency Power Off (EPO) connector	Yes
Serial interface type	RS-232
Modem (RJ-11) ports	2
Serial interface	Yes
RS-232 ports	1

Power

Input operation voltage (min)	60 V
Input operation voltage (max)	150 V
Output operation voltage (min)	100 V
Output operation voltage (max)	125 V
Output power	1350 W
Surge energy rating	1780 J
Output power capacity	1.5 kVA
Input frequency	40 - 70 Hz
Crest factor	3:1
Output voltage Total Harmonic Distortion (THD)	5%
Power factor	0.9
Input power factor	0.99

Technical details

Compliance certificates	RoHS
Sustainability certificates	ENERGY STAR

Weight & dimensions

Width	17" (433 mm)
Height	3.46" (88 mm)
Depth	16.9" (430 mm)
Package width	21.7" (550 mm)
Package height	9.45" (240 mm)
Package depth	23.2" (590 mm)
Package weight	53.8 lbs (24.4 kg)
