3kVA Online Smart APP

Cyberpower

3kVA Online Smart APP

Part #: OL3000RTXL2U Uninterruptible Power Supplies (UPSs)

$2,495.95

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

3KVA SMART APP. ONLINE UPS PURESINE 100-125V LCD L5-30P 2U RT 3YR

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	5 h
Typical backup time at half load	9 min
Typical backup time at full load	3 min
Cold start	Yes
Hot-swap battery	Yes
Battery type	12V/9AH
Number of battery cells	6

Design

Form factor	Rackmount/Tower
Rack capacity	2U
Product colour	Black
Certification	UL1778, CSA C22.2 NO.107.3-05, FCC DOC A
Display type	LCD
Housing material	Steel

General

Manufacturer Part Number	OL3000RTXL2U
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)

Packaging data

Package weight	86.9 lbs (39.4 kg)
Package dimensions (WxDxH)	23.2 x 35 x 8.43" (590 x 890 x 214.1 mm)

Performance

LED indicators	Yes
UPS topology	Double-conversion (Online)
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Network, Telephone
Power protection features	Overload

Physical

Weight	88 lb
Length	34 in
Width	22 in
Height	13 in

Ports & interfaces

AC outlets quantity	7 AC outlet(s)
AC outlet types	NEMA 5–20R, NEMA L5-30R
Power plug	NEMA 5-30P
Cable length	9.84" (0.25 m)
Ethernet LAN (RJ-45) ports	1
Serial ports quantity	1
Modem (RJ-11) ports	1

Power

Input operation voltage (min)	100 V
Input operation voltage (max)	125 V
Output operation voltage (min)	100 V
Output operation voltage (max)	125 V
Output power	2700 W
Output power capacity	3 kVA
Input frequency	40/70 Hz
Crest factor	3:1
Input current Total Harmonic Distortion (THD)	5%
Power factor	0.99

Technical details

Compliance certificates	RoHS

Weight & dimensions

Depth	23.6" (600 mm)
