3KVA ONLINE UPS 2U

Cyberpower

3KVA ONLINE UPS 2U

Part #: OL3000RTXL2UHVN Uninterruptible Power Supplies (UPSs)

$3,495.95

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

SINEWAVE LCD L6-20R 200-240V RMCARD205 RT 3YR Warranty

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	4 h
Battery capacity	9 Ah
Typical backup time at half load	11 min
Typical backup time at full load	3.5 min
Hot-swap battery	Yes
Replacement battery cartridge	RB1290X6A
Battery voltage	12 V
Number of battery cells	6

Design

Form factor	Rackmount/Tower
Rack capacity	2U
Product colour	Black
Safety	UL 1778 5th Ed. CSA C22.2 NO.107.3-05 FCC Part 15 Class A
Display type	LCD
Housing material	Metal

General

Manufacturer Part Number	OL3000RTXL2UHVN
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 45 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%

Packaging data

Cables included	Input power cable

Performance

LED indicators	Yes
Audible alarm modes	Low battery alarm, Overload alarm
UPS topology	Double-conversion (Online)
Waveform	Sine
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Automatic Voltage Regulation (AVR)	Yes

Physical

Weight	86.45 lb

Ports & interfaces

AC outlets quantity	3 AC outlet(s)
Power plug	NEMA L6-30R
Cable length	118.1" (3 m)
Ethernet LAN (RJ-45) ports	1
Modem (RJ-11) ports	1

Power

Input operation voltage (min)	120 V
Input operation voltage (max)	280 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Output frequency	50/60 Hz
Output power	2700 W
Surge energy rating	1335 J
Output power capacity	3 kVA
Input frequency	40/70 Hz
Output frequency regulation	0.25 Hz
Crest factor	3:1
Output voltage regulation	2%
ECO mode	Yes
Input power factor	0.99
Efficiency (ECO mode)	97%
Output power factor	0.9

Technical details

Compliance certificates	RoHS

Weight & dimensions

Width	17" (432 mm)
Height	3.5" (89 mm)
Depth	23.6" (600 mm)
Package width	22" (558.8 mm)
Package height	9.24" (234.7 mm)
Package depth	35.8" (908.6 mm)
Package weight	80.9 lbs (36.7 kg)
