OL750RM UPS

Cyberpower

OL750RM UPS

Part #: OL750RM Uninterruptible Power Supplies (UPSs)

$772.99

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

750VA/600W, 5-15P, 2U, Rackmount

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	4 h
Battery capacity	7 Ah
Battery voltage	12 V

Design

Form factor	Rackmount
Rack capacity	2U
Product colour	Silver
Housing material	Metal

Features

Heat dissipation	174 BTU/h

General

Manufacturer Part Number	OL750RM
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 0.9%
Storage relative humidity (H-H)	0 - 0.95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590511.8" (0 - 14999 m)

Packaging content

Cables included	USB cable
Rack mount kit	Yes

Performance

LED indicators	Power
Audible alarm modes	Overload alarm, Alarm when on battery, Low battery alarm, Fault
UPS topology	Double-conversion (Online)
Waveform	Pure sine
Noise level	42.8 dB
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Number of input phases	1

Physical

Weight	34.83 lb

Ports & interfaces

AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5-15P
Power plug	NEMA 5-15P
Cable length	118.1" (3 m)
USB port	Yes
Emergency Power Off (EPO) connector	Yes
Serial interface	Yes

Power

Input operation voltage (min)	100 V
Input operation voltage (max)	125 V
Output frequency	50/60 Hz
Output power	600 W
Surge energy rating	710 J
Output power capacity	1.5 kVA
Input frequency	40 - 70 Hz
Crest factor	3:1
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	3%
Input current Total Harmonic Distortion (THD)	5%
Power factor	0.8
ECO mode	Yes
Input power factor	0.99
Efficiency (ECO mode)	96%
Output power factor	0.8

Technical details

Compliance certificates	RoHS, UL, Federal Communications Commission (FCC)

Weight & dimensions

Width	17" (433 mm)
Height	3.39" (86 mm)
Depth	14.7" (374 mm)
