1000VA 700W UPS PFC

Cyberpower

1000VA 700W UPS PFC

Part #: OR1000PFCRT2U Uninterruptible Power Supplies (UPSs)

$520.95

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

8 outlet SINE WAVE AVR LCD RACK/TOWER, 1000VA/700W UPS PFC

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	10 h
Battery capacity	12 VAh, 9 Ah
Number of batteries supported	2
Typical backup time at half load	18 min
Typical backup time at full load	6.5 min
Hot-swap battery	Yes
Battery voltage	24 V

Design

Form factor	Rackmount/Tower
Rack capacity	2U
Product colour	Black
Safety	UL 5th, cUL, FCC class A
Display type	LCD

General

Manufacturer Part Number	OR1000PFCRT2U
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Non-operating altitude	0 - 590551.2" (0 - 15000 m)

Packaging data

Manual	Yes
Cables included	Input power cable, Phone (RJ-11), USB cable
Rack mount kit	Yes
Software CD	Yes
Warranty card	Yes

Performance

LED indicators	Power
Audible alarm modes	Alarm when on battery, Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Noise level	48.5 dB
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Automatic Voltage Regulation (AVR)	Yes
Power protection features	Short circuit

Physical

Weight	44.25 lb

Ports & interfaces

AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5–15R
Power plug	NEMA 5-15P
Cable length	94.5" (2.4 m)
Ethernet LAN (RJ-45) ports	2
USB port	Yes
Modem (RJ-11) ports	2

Power

Input operation voltage (min)	88 V
Input operation voltage (max)	139 V
Output operation voltage (min)	86 V
Output operation voltage (max)	142 V
Output power	700 W
Surge energy rating	1470 J
Output power capacity	1 kVA
Input frequency	60 Hz
Output power factor	0.7

Technical details

Compliance certificates	RoHS
Sustainability certificates	ENERGY STAR

Weight & dimensions

Width	17" (432 mm)
Height	3.5" (89 mm)
Depth	15.3" (389 mm)
