Cyberpower

2200VA UPS AVR, 2U RM/T

Part #: OR2200LCDRTXL2U Uninterruptible Power Supplies (UPSs)

$905.95

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

2190VA / 1650W Intelligent, Line-Interactive UPS with Smart App Software, AVR, 2U RM/T, 17.2 AMP, 8 x NEMA 5-20R, RJ11/RJ45/Coax, USB/Serial, SNMP/HTTP (optional), Extended Battery Packs Available. "hot swappable" battery change capability

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	8 h
Typical backup time at half load	14 min
Typical backup time at full load	6 min
Hot-swap battery	Yes
Battery type	12 V, 9 Amph

Design

Form factor	Rackmount/Tower
Rack capacity	2U
Product colour	Black
Certification	UL1778, cUL 107.3, FCC DOC Class B
Display type	LCD

General

Manufacturer Part Number	OR2200LCDRTXL2U
Country of Origin	PH

Operational conditions

Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	0 - 90%

Other features

Management platform	SNMP, HTTP

Packaging data

Bundled software	PowerPanel BusinessEd

Performance

LED indicators	Yes
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Surge protection	Yes
Surge protection features	Coax, Network, Telephone
Power protection features	Overload

Physical

Weight	89.5 lb

Ports & interfaces

AC outlets quantity	8 AC outlet(s)
AC outlet types	NEMA 5–20R
Cable length	118.1" (3 m)
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	1
Serial ports quantity	2
Modem (RJ-11) ports	1

Power

Input operation voltage (min)	90 V
Input operation voltage (max)	140 V
Output operation voltage (min)	110 V
Output operation voltage (max)	130 V
Output power	1650 W
Surge energy rating	2060 J
Output power capacity	2.19 kVA

Technical details

Compliance certificates	RoHS

Weight & dimensions

Width	17" (431.8 mm)
Height	3.5" (88.9 mm)
Depth	18.8" (477.5 mm)
