2200VA/2200W Sine Wave UPS

Cyberpower

2200VA/2200W Sine Wave UPS

Part #: PR2200RTXL2UHVAN Uninterruptible Power Supplies (UPSs)

$1,591.99

Quote for availability

Listed price is an estimate — this item is quoted before purchase.

Genuine, sourced-to-order hardware
Secure checkout
Volume pricing by quote

Request a Quote

Availability and lead time confirmed before fulfillment
Compatible alternatives suggested when a part is constrained
Volume and project pricing available on request

Product Overview

2200VA/2200W Sine Wave UPS 2U, 4xNEMA 6-20R 2xNEMA L6-20R

Specifications

Battery

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3 h
Battery capacity	6 Ah
Typical backup time at half load	15.2 min
Typical backup time at full load	5.3 min
Hot-swap battery	Yes
Replacement battery cartridge	RB1260X8
Battery voltage	12 V
Number of battery cells	8

Design

Form factor	Rackmount/Tower
Product colour	Black
Safety	CE, UL1778, FCC Class A, VCCI
Display type	LCD
Housing material	Metal

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-15 - 45 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%

Packaging data

Cables included	Input power cable

Performance

LED indicators	Yes
Audible alarm modes	Low battery alarm, Overload alarm
UPS topology	Line-Interactive
Waveform	Sine
Response time	4 ms
Audible alarm(s)	Yes
EMI/RFI noise filtering	Yes
Automatic Voltage Regulation (AVR)	Yes

Ports & interfaces

AC outlets quantity	6 AC outlet(s)
Power plug	NEMA L6-20P
Cable length	118.1" (3 m)
Ethernet LAN (RJ-45) ports	1
USB port	Yes
Emergency Power Off (EPO) connector	Yes
Serial interface	Yes

Power

Input operation voltage (min)	148 V
Input operation voltage (max)	288 V
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Maximum current	20 A
Output frequency	50/60 Hz
Output power	2200 W
Surge energy rating	2430 J
Output power capacity	2.2 kVA
Input frequency	47/63 Hz
Output voltage regulation	5%

Technical details

Compliance certificates	RoHS

Weight & dimensions

Weight	92.6 lbs (42 kg)
Width	17.1" (434 mm)
Height	3.39" (86 mm)
Depth	24.8" (630 mm)
Package width	22.5" (571.5 mm)
Package height	10.5" (266.7 mm)
Package depth	29.7" (755.6 mm)
Package weight	112 lbs (50.8 kg)
